Two years ago, I was pondering ways to enhance borrowck with proof-based analysis. At the time, I was only aware of formal verification tools for functional languages, while Rust is impure. For the purposes of borrow checking, though, we can almost pretend that impurity doesn’t exist, with the notable exception of mutable references.
Can mutable references be simulated in a functional language? Representing memory as a byte array doesn’t compose: while call order is usually irrelevant in functional code, adding address-indexed memory to the mix requires proving non-aliasing even in trivial cases. And using path-indexed memory, like root.var.field[index], doesn’t work for stack locals and objects with complex ownership.
I couldn’t find a fix and dropped the topic. Until a few days ago, when I needed to implement mutable references in functional code for a pet project and realized just how instrumental aliasing XOR mutability and lifetimes are in achieving this.
An important disclaimer: while my method captures many operations with mutable references correctly, there’s a missing detail that makes it unsuitable for typical Rust code. I don’t know if it can be fixed, and I’d like to hear your thoughts on the topic.
Regardless, it feels odd how a tool invented for Rust applies so well to functional code, and I hope you’ll agree the similarity is eerie once you read this post. I think there’s some convergence here: my approach is reminiscent of Polonius, the borrow checker that will replace the current NLL, to the point where when I first heard of how borrowck works in rustc, I was confused why it wasn’t Polonius from day one.
fn f(r: &mut i32) {
*r += 1;
}
An easy way to do this is to receive the old value of r and return the new one:
fn f_rewritten(r: i32) -> i32 {
r + 1
}
Callers can then replace f(&mut x) with x = f_rewritten(x). Note that I allow assignment to locals and focus specifically on removing references. In other words, my goal is only to make all functions pure, not change the programming paradigm. Replacing imperative constructs like if and for statements and reassignments can occur as a later stage if necessary.
With more input references, we just take and return more values:
fn f(r1: &mut i32, r2: &mut i32) {
*r1 += 1;
*r2 += 1;
}
fn f_rewritten(r1: i32, r2: i32) -> (i32, i32) {
(r1 + 1, r2 + 1)
}
This rewrite works as long as r1 and r2 don’t alias. This reminds me of unique ownership: an alternative formulation for what we’re doing here is that taking a mutable reference temporarily transfers ownership of the value to the reference. A place cannot be mutably borrowed twice at the same time, or we’ll encounter stale data, and for the same reason, the value can’t be read from the original location until the mutable reference dies. This is the same check that borrowck implements.
fn f(r1: &mut i32, r2: &mut i32) {
let mut vec: Vec<&mut i32> = vec![r1, r2];
shuffle(&mut vec);
*vec[0] += 1;
*vec[1] += 2;
}
To rewrite this, we need to somehow know which order to return the new values in:
fn f_rewritten(r1: i32, r2: i32) -> (i32, i32) {
let mut vec: Vec<i32> = vec![r1, r2];
vec = shuffle(vec);
vec[0] += 1;
vec[1] += 2;
// (vec[0], vec[1])? (vec[1], vec[0])?
}
To avoid tracking it manually, let’s return an unordered set of mutated references, and require the caller to add a source marker to reference values to distinguish them:
fn f_rewritten(r1: (Source, i32), r2: (Source, i32)) -> Vec<(Source, i32)> {
let mut vec: Vec<(Source, i32)> = vec![r1, r2];
vec = shuffle(vec);
vec[0].1 += 1;
vec[1].1 += 2;
vec
}
fn example_call() -> i32 {
let mut a = 1;
let mut b = 2;
f(&mut a, &mut b);
a - b
}
fn example_call_rewritten() -> i32 {
let mut a = 1;
let mut b = 2;
for (source, new_value) in f_rewritten((Source::A, a), (Source::B, b)) {
match source {
Source::A => a = new_value,
Source::B => b = new_value,
}
}
a - b
}
Since the caller adds the marker, not the callee, the rewritten argument and return types match, and there is no special-casing. (Source, T) becomes our representation of &mut T, and we require that functions return all references from their arguments:
struct RefMut<T> {
source: Source,
value: T,
}
This may look limiting – for instance, it makes std::mem::forget unsound – but it’s actually not that bad. Rust already inserts calls to drop glue when values need to be destroyed to prevent memory leaks, and that covers everything but Rc/Arc and unsafe code. And putting mutable references in Rc is not that common.
So all we need to do is replace drop glue with something that can surface references into callers, so that references are consumed in scopes where the corresponding locals can be updated. We’ll discuss how exactly to do this in a bit.
fn f(r: &mut i32) { ... }
fn g(r: &mut i32) {
f(r);
f(r);
}
In Rust, &mut T is !Copy, so it looks like the first call f(r) should move r into f’s arguments and make r unusable for the rest of g. Luckily, due to reborrowing, the first call is effectively rewritten to f(&mut *r), so this works.
In functional code, such reborrowing is unnecessary
because we have linear types, so f is guaranteed to return r back:
fn f_rewritten(r: RefMut<i32>) -> RefMut<i32> { ... }
fn g_rewritten(mut r: RefMut<i32>) -> RefMut<i32> {
r = f_rewritten(r);
f_rewritten(r)
}
fn f(r: &mut i32) { ... }
fn f_rewritten(r: RefMut<i32>) -> RefMut<i32> { ... }
fn example_call() {
let mut a = [[1, 2], [3, 4]];
f(&mut a[0][0]);
}
fn example_call_rewritten() {
let mut a = [[1, 2], [3, 4]];
a = [[f(RefMut { source: ???, value: a[0][0] }).value, a[0][1]], a[1]];
}
The source here doesn’t have to include the entire path a[0][0], it only needs to distinguish this reference from other references passed to f. In this case, there are no such references, so it can be empty.
fn f<'a, 'b, T>(r1: &'a mut T, r2: &'b mut T) {
// doesn't compile: core::mem::swap(r1, r2);
}
// Always returns reference associated with `'a` in `.0`, reference associated with `'b` in `.1`.
fn f_rewritten<T>(r1: RefMut<T>, r2: RefMut<T>) -> (RefMut<T>, RefMut<T>) { ... }
So a source corresponds to all borrow expressions with a given lifetime. With a sleight of hand, we can associate a lifetime with a set of borrow expressions it includes, and say that &'a mut T is just ('a, T).
This is actually less crazy than it sounds. For Polonius, a lifetime is a set of borrow expressions. (For comparison, NLL says that a lifetime is a program location where the reference may be accessed, that is, it tracks consumers rather than producers.)
fn f<'a, 'b, T>(r1: &'a mut T, r2: &'b mut T) {}
fn f_rewritten<'a, 'b, T>(r1: ('a, T), r2: ('b, T)) -> (Set<'a>, Set<'b>) {
(Set::new([r1]), Set::new([r2]))
}
When f is invoked, its caller knows which lifetimes correspond to borrows within the caller, and which lifetimes forward external borrows. It can then consume some references within the function, and merge others into its own returned set:
fn g<'a>(r1: &'a mut i32) {
let mut x = 123;
f(r1, &mut x);
}
fn g_rewritten<'a>(r1: ('a, i32)) -> Set<'a> {
let mut x = 123;
let (set_a, set_local) = f(r1, (Source::X, x));
for (source, new_value) in set_local {
match source {
Source::X => x = new_value,
}
}
set_a
}
fn h() {
let mut x = 123;
let mut y = 456;
f(&mut x, &mut y);
}
fn h_rewritten() {
let mut x = 123;
let mut y = 456;
let (set_x, set_y) = f((Source::X, x), (Source::Y, y));
for (source, new_value) in set_x {
match source {
Source::X => x = new_value,
}
}
for (source, new_value) in set_y {
match source {
Source::Y => y = new_value,
}
}
}
fn i<'a>(r1: &'a mut i32, r2: &'a mut i32) {
f(r1, r2);
}
fn i_rewritten<'a>(r1: &'a mut i32, r2: &'a mut i32) -> Set<'a> {
let (set_a, set_b) = f(r1, r2);
set_a.merge(set_b)
}
Drop glue can behave similarly, returning the per-lifetime sets of dropped references stored within the dropped value.
fn f(r: &mut (i32, i32)) -> &mut i32 {
r.0 += 1;
&mut r.1
}
We can return a reference to a subfield of the passed value, while mutating the original value. In this case, there is no one to perform the write-back, because f has already completed by the time the returned &mut i32 is destroyed. And we can’t just write-back r after calling f because it can still be modified through the field reference.
So the new value of r, the source of r, and the field name can only be stored in the returned &mut i32 – more specifically, in its source:
enum Source {
Projection(RefMut, Field),
...
}
fn f_rewritten(r: RefMut<(i32, i32)>) -> RefMut<i32> {
r.value.0 += 1;
(Source::Projection(r, 1), r.value.1)
}
When the field reference is destroyed, we update everything up to the original object:
for r in set {
while let Self::Projection(r, field) = r.source {
r.value[field] = r.value;
r = r.to_base();
}
match r.source {
...
}
}
This ties into some of my other points:
When talking about lifetimes, I brought up separating references into sets by lifetimes, but I ignored pointee types. This is because when projections are added to the mix, the types of the original pointee and the current pointee need not agree, so this might draw a distinction that doesn’t exist.
Simulating reborrows with linear types becomes trickier: when calling f_rewritten(r) in question with r from an argument, you can’t do write-back it with while let ... because r itself might be a projection, so you either need while r.source != original_source, or perform reborrowing explicitly with f(&mut *r). The latter is simpler and closer to how Rust actually behaves.
Anyway, this is hacky, but at least it seemingly works. The issue is that it fails spectacularly when more than one field is projected:
fn f(r: &mut (i32, i32, i32)) -> (&mut i32, &mut i32) {
r.0 += 1;
(&mut r.1, &mut r.2)
}
With my design, you’d have to duplicate r to return two projected references, which would cause collisions on write-back. Worst-case scenario, we can have a highly nested tree of updates that need to be committed at once. Maybe we could look at the set of dying references to recover the tree? But this requires object-addressed maps, i.e. either a hash map (slow), or straight up mutating objects (impure).
It obviously demonstrates that it’s possible to simulate mutable references almost entirely in functional code. Also, this ties neatly into the linear type-based aliasing story by showing that it’s mostly equivalent to lifetimes (e.g. by the Vale guy).
Whether this has other applications or I’m reinventing the wheel, I don’t know.
